Front Wheel Drive Diesel Mini Loader for Construction and Farm
Compact front wheel drive diesel mini loader for construction sites and farm use. Small footprint with efficient loading capability. CE and ISO certified.
- Engine: 22-30 kW (30-40 HP) Diesel
- Bucket Capacity: 0.4 m3
- Operating Weight: 1800 kg
- Drive Type: FWD
- Max Speed: 20 km/h
- Certification: CE, ISO
Product Overview
The Jinlonglutai front wheel drive mini diesel loader is an economical and compact solution for light construction and farm material handling. Its small footprint and front-wheel-drive configuration make it ideal for operation in tight spaces and on flat terrain.
Compact Design
The minimal overall dimensions allow operation in narrow alleys, small barns, greenhouse passages, and backyard construction sites. The front-wheel-drive layout simplifies maintenance and reduces manufacturing cost, providing excellent value for budget-conscious buyers.
Applications
Perfect for farm barn cleaning, small construction material handling, landscaping, snow removal, and light earthmoving. The standard bucket handles soil, sand, gravel, feed, and general loose materials efficiently.
Economical Choice
Fuel-efficient single-cylinder diesel engine delivers low operating cost. Simple mechanical design ensures easy maintenance without specialized tools. CE and ISO certified by Jinlonglutai factory in Qingdao, China.
Technical Specifications
| Engine Model | Single Cylinder Diesel (30-40 HP) |
| Rated Power | 22-30 kW |
| Operating Weight | 1800 kg |
| Bucket Capacity | 0.4 m3 |
| Max Lifting Height | 2400 mm |
| Max Dumping Height | 2200 mm |
| Drive Type | Front Wheel Drive |
| Transmission | Mechanical Gearbox |
| Max Speed | 20 km/h |
| Overall Dimensions | 3800 x 1500 x 2300 mm |
| Tire Size | 10.00-16 |
| Gradeability | 20 deg |
| Hydraulic Pressure | 14 MPa |
