China Crawler Mini Hydraulic Excavator CE Certified
Compact China-made crawler mini hydraulic excavator with CE certification. 1-ton class with reliable diesel engine, ideal for landscaping, small construction, agricultural and urban renovation projects. Factory direct from Shandong, China.
- Operating Weight: 1,000 kg
- Engine Power: 10 HP (7.5 kW)
- Max Digging Depth: 1,800 mm
- Bucket Capacity: 0.02 m³
Варианты моделей
| Name | Options |
|---|---|
| Quantity | {'value': '1-9 sets', 'price': '$4,800 / set'}, {'value': '10-29 sets', 'price': '$4,650 / set'}, {'value': '≥30 sets', 'price': '$4,500 / set'} |
Application Scenarios
This CE-certified mini crawler excavator is designed for versatile small-scale operations. Perfect for residential landscaping, garden trenching, agricultural farm work, indoor demolition, and urban renovation projects where space is limited. The compact 960mm width allows access through standard doorways and narrow passages.
Customization Options
We offer comprehensive customization to match your specific project needs. Choose from multiple bucket sizes, add hydraulic breaker hammers for demolition work, auger drills for fence post installation, or rakes for landscaping. Custom paint colors and OEM branding available for bulk orders.
Production & Delivery
With 88,000m2 production plant and 300+ units monthly capacity for mini excavators, we guarantee timely delivery. Standard lead time is 7-20 working days depending on configuration. Sample and trial orders are welcome with fast turnaround.
Certificates & Quality Assurance
All mini excavators are CE and ISO 9001 certified, meeting European safety and quality standards. Each unit undergoes rigorous testing including hydraulic system pressure testing, track alignment check, and full operational trial before shipping. Complete documentation provided for smooth customs clearance.
Technical Specifications
| Model | JL-ME-1000 |
| Machine Type | Hydraulic Crawler Mini Excavator |
| Moving Type | Crawler |
| Operating Weight | 1,000 kg |
| Engine Brand | Laidong/Kubota |
| Engine Power | 10 HP (7.5 kW) |
| Bucket Capacity | 0.02 m³ |
| Max Digging Height | 2,550 mm |
| Max Digging Depth | 1,800 mm |
| Max Digging Radius | 2,800 mm |
| Max Dumping Height | 1,900 mm |
| Swing Speed | 10 rpm |
| Travel Speed | 1.8 km/h |
| Grade Ability | 30° |
| Hydraulic System Pressure | 16 MPa |
| Track Width | 180 mm |
| Track Gauge | 760 mm |
| Min Ground Clearance | 150 mm |
| Overall Dimensions (LxWxH) | 2,800 x 960 x 1,550 mm |
| Certification | CE, ISO 9001 |
| Brand Name | JINLONGLUTAI |
| Place of Origin | Shandong, China |
| Warranty | 1 Year |
| Core Components | Engine, Hydraulic Pump, Hydraulic Valve, Cylinders, Tracks |
